atHelloWorld build project error

[ajayrawat707]

* Executing task: mkapp ${LEGATO_DEF_FILE} -s components -t ${LEGATO_TARGET} -w ${LEGATO_OBJECT_DIR} -o ${LEGATO_OUTPUT_DIR} && update ${LEGATO_UPDATE_FILE}

[1/7] Compiling C source

FAILED: /home/user/Desktop/workspace/legato-af-master/_build_atHelloWorldTest/wp76xx/component/7c0045bcc82f724a3076b37cde1889f9/obj/6f76d9aae15904c80a25537be805ee48.o

/home/user/Desktop/workspace/legato-af-master/leaf-data/testing/wp76-toolchain/sysroots/x86_64-pokysdk-linux/usr/bin/arm-poky-linux-gnueabi/arm-poky-linux-gnueabi-gcc --sysroot=/home/user/Desktop/workspace/legato-af-master/leaf-data/testing/wp76-toolchain/sysroots/armv7a-neon-poky-linux-gnueabi -MMD -MF /home/user/Desktop/workspace/legato-af-master/_build_atHelloWorldTest/wp76xx/component/7c0045bcc82f724a3076b37cde1889f9/obj/6f76d9aae15904c80a25537be805ee48.o.d -Wall -Werror -fvisibility=hidden -c /home/user/Desktop/workspace/legato-af-master/apps/test/atServices/atServerHelloWorld/atHelloWorldComponent/atHelloWorld.c -o /home/user/Desktop/workspace/legato-af-master/_build_atHelloWorldTest/wp76xx/component/7c0045bcc82f724a3076b37cde1889f9/obj/6f76d9aae15904c80a25537be805ee48.o -DLE_FILENAME=`basename /home/user/Desktop/workspace/legato-af-master/apps/test/atServices/atServerHelloWorld/atHelloWorldComponent/atHelloWorld.c` -DMK_TOOLS_BUILD -DLEGATO_EMBEDDED -fPIC -I /home/user/Desktop/workspace/legato-af-master/_build_atHelloWorldTest/wp76xx -I/home/user/Desktop/workspace/legato-af-master/leaf-data/testing/wp76-legato/interfaces -I/home/user/Desktop/workspace/legato-af-master/leaf-data/testing/wp76-legato/framework/include -I/home/user/Desktop/workspace/legato-af-master/leaf-data/testing/wp76-legato/build/wp76xx/framework/include -I/home/user/Desktop/workspace/legato-af-master/apps/test/atServices/atServerHelloWorld -I/home/user/Desktop/workspace/legato-af-master/_build_atHelloWorldTest/wp76xx/component/7c0045bcc82f724a3076b37cde1889f9/src -DLE_COMPONENT_NAME=atHelloWorldComponent -DLE_LOG_SESSION=atHelloWorldComponent_LogSession -DLE_LOG_LEVEL_FILTER_PTR=atHelloWorldComponent_LogLevelFilterPtr

/home/user/Desktop/workspace/legato-af-master/apps/test/atServices/atServerHelloWorld/atHelloWorldComponent/atHelloWorld.c:9:10: fatal error: atServerIF.h: No such file or directory

#include “atServerIF.h”

      ^\~\~\~\~\~\~\~\~\~\~\~\~\~

compilation terminated.

ninja: build stopped: subcommand failed.

* The terminal process “/usr/bin/bash ‘-c’, ‘mkapp ${LEGATO_DEF_FILE} -s components -t ${LEGATO_TARGET} -w ${LEGATO_OBJECT_DIR} -o ${LEGATO_OUTPUT_DIR} && update ${LEGATO_UPDATE_FILE}’” terminated with exit code: 1.

* Terminal will be reused by tasks, press any key to close it.

[ajayrawat707]

[jyijyi]

Which module are you using?

which firmware are you using?

Even the latest firmware R17 with legato 21.05, I don’t see such application:

legato-af/apps/test/atServices at 21.05-release · legatoproject/legato-af

[ajayrawat707]

module wp7608
legato 20.08.0

[jyijyi]

i don’t see such application in this legato version:

legato-af/apps/test/atServices at 20.08-release · legatoproject/legato-af

[ajayrawat707]

i am using Master branch

[jyijyi]

there is no official firmware for this master branch

[ajayrawat707]

can u help me….. i have wp7608 modem i have github repo legato AF i want to any one service build to to Test AT command

[jyijyi]

i don’t even see the atServerIF.h.

can you see this file in your main branch of source code?

BTW, what do you want to do with the application?

Maybe we have other sample code to meet your purpose.

[ajayrawat707]

basically i want open AT command like AT+jyijyi its return hii or something

how to i can make this cmd understand my issue???

[jyijyi]

you can see here for custom AT command:

AT cmds for Mirage Talon from MangoH Red board AT port

[ajayrawat707]

(lsh:test) user@user-Precision-Tower-3620:~/Downloads/UART_KHTTP_Demo1$ mkapp -t wp76xx atServerIntegrationTest.adef
** ERROR:
/home/user/Downloads/UART_KHTTP_Demo1/atServerTestComp/Component.cdef:6:8: error: * Couldn’t find file ‘le_mcc.api.’
(lsh:test) user@user-Precision-Tower-3620:~/Downloads/UART_KHTTP_Demo1$ this error will come when i am build from Cmd and also i tried with VSCode and getting same error: * Couldn’t find file ‘le_mcc.api.’

[jyijyi]

you need to add some more parameter in mkapp command line:

FX30S - Build Error - Couldn't find file 'le_avc.api'

Here is my example on helloworld sample: in hello1.adef, add bindings: { hello1.hello1Component.le_avc → avcService.le_avc } in Component.cdef, add requires: { api: { le_avc.api } } leaf shell (lsh:swi-wp76_4.7.0) owner@ubuntu:~/leaf/apps/Demo/hello1$ mkapp ${LEGATO_DEF_FILE} -s components -t ${LEGATO_TARGET} -w ${LEGATO_OBJECT_DIR} -o ${LEGATO_OUTPUT_DIR} -i ${LEGATO_ROOT}/interfaces/airVantage

Unknown error in "atServerIntegrationTest" due to specific API loading

AT cmds for Mirage Talon from MangoH Red board AT port

[ajayrawat707]

FAILED: /home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/component/a80dbb63607285cfa34f1fa6c5fcdb81/obj/9c07e8f60fe34387bde34bcc36d6f963.o
/home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-toolchain/sysroots/x86_64-pokysdk-linux/usr/bin/arm-poky-linux-gnueabi/arm-poky-linux-gnueabi-gcc --sysroot=/home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-toolchain/sysroots/armv7a-neon-poky-linux-gnueabi -MMD -MF /home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/component/a80dbb63607285cfa34f1fa6c5fcdb81/obj/9c07e8f60fe34387bde34bcc36d6f963.o.d -Wall -Werror -fvisibility=hidden -c /home/user/Desktop/UART_KHTTP_Demo1/atServerTestComp/atServerTest.c -o /home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/component/a80dbb63607285cfa34f1fa6c5fcdb81/obj/9c07e8f60fe34387bde34bcc36d6f963.o -DLE_FILENAME=basename /home/user/Desktop/UART_KHTTP_Demo1/atServerTestComp/atServerTest.c -DMK_TOOLS_BUILD -DLEGATO_EMBEDDED -fPIC -I /home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx -I/home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-legato/interfaces -I/home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-legato/framework/include -I/home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-legato/build/wp76xx/framework/include -I/home/user/Desktop/UART_KHTTP_Demo1 -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/component/a80dbb63607285cfa34f1fa6c5fcdb81/src -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/6b3d4c5315c3e74255ca066d5234ad6e -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/6b3d4c5315c3e74255ca066d5234ad6e -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/6b3d4c5315c3e74255ca066d5234ad6e/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/6b3d4c5315c3e74255ca066d5234ad6e/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/4f8367b7a2dc033771364b78fc781535 -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/4f8367b7a2dc033771364b78fc781535 -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/4f8367b7a2dc033771364b78fc781535/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/4f8367b7a2dc033771364b78fc781535/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/12c6fd07adc4341ee4e298e27a247d0f -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/12c6fd07adc4341ee4e298e27a247d0f/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/944ff3e3d40feb684def4e2e6e467664 -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/944ff3e3d40feb684def4e2e6e467664/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/12c6fd07adc4341ee4e298e27a247d0f/client -I/home/user/Desktop/UART_KHTTP_Demo1/_build_atServerIntegrationTest/wp76xx/api/944ff3e3d40feb684def4e2e6e467664/client -DLE_COMPONENT_NAME=atServerTestComp -DLE_LOG_SESSION=atServerTestComp_LogSession -DLE_LOG_LEVEL_FILTER_PTR=atServerTestComp_LogLevelFilterPtr
In file included from /home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-legato/framework/include/legato.h:188:0,
from /home/user/Desktop/UART_KHTTP_Demo1/atServerTestComp/atServerTest.c:47:
/home/user/Desktop/UART_KHTTP_Demo1/atServerTestComp/atServerTest.c: In function ‘AtCmdHandler’:
/home/user/Desktop/UART_KHTTP_Demo1/atServerTestComp/atServerTest.c:736:15: error: implicit declaration of function ‘le_atServer_SendFinalResponse’; did you mean ‘le_atServer_SendFinalResultCode’? [-Werror=implicit-function-declaration]
LE_ASSERT(le_atServer_SendFinalResponse(commandRef, LE_ATSERVER_OK, false, “”) == LE_OK);
^
/home/user/Desktop/UART_KHTTP_Demo1/leaf-data/test/wp76-legato/framework/include/le_log.h:981:9: note: in definition of macro ‘LE_FATAL_IF’
if (condition) { LE_FATAL(formatString, ##VA_ARGS); }
^~~~~~~~~
/home/user/Desktop/UART_KHTTP_Demo1/atServerTestComp/atServerTest.c:736:5: note: in expansion of macro ‘LE_ASSERT’
LE_ASSERT(le_atServer_SendFinalResponse(commandRef, LE_ATSERVER_OK, false, “”) == LE_OK);
^~~~~~~~~
cc1: all warnings being treated as errors
ninja: build stopped: subcommand failed.

• The terminal process “/usr/bin/bash ‘-c’, ‘mkapp ${LEGATO_DEF_FILE} -s components -t ${LEGATO_TARGET} -w ${LEGATO_OBJECT_DIR} -o ${LEGATO_OUTPUT_DIR}’” terminated with exit code: 1.
• Terminal will be reused by tasks, press any key to close it.

[jyijyi]

I don’t see such problem with R16.3 (legato 19.11.6)

(lsh:wp76) owner@ubuntu:~/leaf/apps/Demo/UART_KHTTP_Demo1$ mkapp -t wp76xx -o Target_Legato_Debug -w Target_Legato_Debug -i ${LEGATO_ROOT}/interfaces/modemServices atServerIntegrationTest.adef
[22/22] Packaging app

[ajayrawat707]

Hi jyijyi, now i am able to compile the code and run it on the modem which you have provided, can you specify me from where i can pick the APIs for making customize AT cmd in the code you have provided so i can start with my work

[jyijyi]

you can diff to the original code to know what I add to the source code:

legato-af/apps/test/atServices/atServerIntegrationTest at master ·...

[ajayrawat707]

i want to make

The Input will be like AT+plm

And it should scan the PLMN using the API le_mrc_ScanNetworks() and return the list of operators.

can u share a code with me i am stucked???

[jyijyi]

why don’t you just use “AT+COPS=?”

[ajayrawat707]

basically i want make my own command that’s why i am asking can u help???
